V1 to V2 was upgraded for the DJI O3 HD Air Unit Digital Transmission
Specially Designed Heatsink for DJI O3 Air Unit
New Camera Mount for a wider camera FOV with TPU damping inserts
New Side Panels to perfectly fit the DJI O3 Air Unit in the back
New Dual 5.8G VTX Antenna TPU mount
Latest Nazgul Frame Upgrades for Maximum Protection

Specification:

Brand: iFlight

Model: Evoque F6 V2

Product Name: 6 Inch Freestyle Frame Kit

Optional Version: F6X ( Squashed X) / F6D (DeadCat)
Frame wheelbase: 255mm (Squashed X) / 262 mm (DeadCat)
Frame Dimension: L196*W164*H36 mm (Squashed X) / L209*W162*H36 mm (DeadCat)
Frame Body Dimension: 36mm
Arm Thickness: 6mm
Bottom Plate Thickness: 3mm
Top Plate Thickness: 2mm
Upper Plate Thickness: 3mm
Camera Plate Thickness: 3mm
Motor Mounting: 16x16mm
VTX Mounting: 25.5*25.5 φ1.6mm
Weight: 150grams (Included no TPU Parts)

Package Included:

1 x Evoque F6 V2 Frame Kit
1 x Heatsink for DJI O3 Air Unit
2 x IPEX to RP-SMA Antenna Pigtails for DJI O3 Air Unit
1 x Dual Antenna TPU for DJI O3 Air Unit
1 x TPU Base Mount for GoPro
1 x Screw Bag
4 x TPU Armguard
1 x Front Bumper TPU
1 x Rear Bumper TPU
2 x Anti-slip Battery Pad
2 x Battery Strap (20*250mm)
1 x Battery Strap(20*250mm)
