Specifications:

Frequency Range: 1.5u201360MHz
Power Range: 0.2W to 120W
S.W.R. Range: 1:1u201319.99:1
V.S.W.R Measure: Minimum Power Required = 2W for Full Scale Display
Maximum Power: 120W
Accuracy: ±5% (Average)
Beep Alarm: S.W.R 2:1
Input/Output Impedance: 50 ohms
Input/Output Connectors: SO239
Size (including connectors): 88(W) x 40(H) x 80(D) mm
Weight: 175g
Battery: Built-in 500mAh Li-ion Rechargeable Battery


Features:

1.Wide Measurement Range
Operates across 1.5u201360MHz frequency range, making it compatible with diverse HF radio systems for enhanced versatility.
2.High Power Capability
Supports a maximum power range of up to 120W, catering to both low and high-power applications efficiently.
3.User-Friendly Display
Features a large and clear meter display with forward and reflected RF power readings for easy and accurate monitoring, simplifying operations for users.
4.Portable and Lightweight Design
Compact and weighing only 175g, this device is ideal for on-the-go use, offering convenience in mobile communication setups.
5.Modern USB Charging System
Equipped with a Type-C USB charging port and a built-in 500mAh rechargeable battery for seamless charging and extended usability.


Package Includes:

1 x HF Power & SWR Meter
1 x English Instructions
1 x Type-C Charger Cable
