Retour PolitikProduct Model(NOTE:Click on the model to reach the purchase link of the corresponding model) :
| Model | Channels | Bandwidth | Sampling Rate | Storage Depth | Signal Source (AWG) |
| >>DSO2C10<< | 2CH | 100MHz | 1GSa/S | 8M | / |
| 2CH | 150MHz | 1GSa/S | 8M | / | |
| 2CH+1CH | 100MHz | 1GSa/S | 8M | 1CH | |
| 2CH+1CH | 150MHz | 1GSa/S | 8M | 1CH |
Parameters
| Model | DSO2D15 | DSO2D10 | DSO2C15 | DSO2C10 |
| Bandwidth | 150MHz | 100MHz | 150MHz | 100MHz |
| Oscilloscope channels | 2CH | 2CH | 2CH | 2CH |
| Waveform generator | 1CH | 1CH | - | - |
| Oscilloscope | ||||
| Sample rate | 1GSa/s (single channel) 500MSa/s (two channels) | |||
| Acquisition | ||||
| Sampling | Sample data | |||
| Peak-to-peak value | Display high frequency and random burr | |||
| Average | Average waveform, times: 4, 8, 16, 32, 64, 128 | |||
| High resolution | Up to 12bit | |||
| Input | ||||
| Input coupling | DC, AC, GND | |||
| Input impedance | 1MΩ±2% u201620pF±3pF | |||
| Probe attenuation factor | 1X, 10X, 100X, 1000X | |||
| Voltage classes | 300V CAT II | |||
| Maximum input voltage | 300VRMS (10X) | |||
| Horizontal | ||||
| Waveform interpolation | (sin x)/x | |||
| Maximum record length | Single channel maximum 8M | |||
| Two channels maximum 4M | ||||
| Horizontal scale range | 2ns/div~100s/div 1, 2, 5 step by step | |||
| Time base mode | Y-T, X-Y, Roll | |||
| Zero offsets | ±0.5 div×minimum time base gear | |||
| Sample Rate and Delay Time Accuracy | ±25ppm | |||
| Clock drifting | ≤±5 ppm/year | |||
| Increment Time Measurement Accuracy | single, ""acquisition"" mode | |||
| (Full Bandwidth) | ±(1 sample interval+100ppm×reading+0.6ns) | |||
| uff1e16 times averages | ||||
| ±(1 sample interval+100ppm×reading+0.4ns) | ||||
| Sample interval=sec/div÷200 | ||||
| Sample Rate and Delay Time Accuracy | ±50ppm(at any interval greater than 1ms) | |||
| Vertical | ||||
| Model | DSO2D15 | DSO2D10 | DSO2C15 | DSO2C10 |
| Bandwidth | 150MHz | 100MHz | 150MHz | 100MHz |
| Rising time in BNC position (typical) | 2.3ns | 3.5ns | 2.3ns | 3.5ns |
| Vertical resolution | 8 bits resolution, each channel samples simultaneously | |||
| Vertical sensitivity | 2mV/div to 10V/div | |||
| Offsets range | 2mV/div to 20mV/div, ±100mV; 50mV/div to 200mV/div, ±1V; | |||
| 500mV/div to 2V/div, ±10V; 5V/div to 10V/div, ±50V | ||||
| Mathematical operation | +, -, ×, ÷, FFT | |||
| FFT | Window: Rectangular, Hanning, Hamming, Brackman, Bartlett, flat top window | |||
| Bandwidth Limit | 20MHz | |||
| Bass response(-3db) | In BNC position ≤ 10Hz | |||
| Vertical gain accuracy | In ""normal"" or ""average"" acquisition mode, the accuracy of 10V/div to 10mV/div is ±3%; | |||
| In ""normal"" or ""average"" acquisition mode, the accuracy of 5mV/div to 2mV/div is ±4% | ||||
| DC offsets accuracy |
Reviews(106)
4.90
See All Reviews
Questions & Answers(21)
Q: Hello from France
I would like to buy the Hantek DSO2D15 oscilloscope.
On your presentation page it is written in the DSO2C15 information line but on the picture it is written on the front of the DSO2D15.
Please what is the correct part number you are selling?
Thank you for the answer. Yours sincerely
Pascal
3 answers
Q: vc tem esse ocilioscopio a ponta entrega?
2 answers
